DIAPHRAGM TYPES

LEARN MORE ABOUT OUR DIAPHRAGM TYPES

FABRIC REINFORCED
The core of our business. The diaphragm type on which our reputation was built.

DIAPHRAGM TYPES
FABRIC REINFORCED



The diaphragm utilizes a layer of fabric during the molding process. This offers a wide range of design flexibility. The fabric allows the diaphragm to withstand higher pressures while also remaining very flexible in the process. All elastomers can be constructed as a fabric reinforced diaphragm.

DOUBLE COATED
Elastomer on both sides for added strength and high performance in double-pressure applications.

DIAPHRAGM TYPES
DOUBLE COATED



Some diaphragm applications require that the rolling diaphragm be coated with rubber on both sides. This type of diaphragm is typically required when the application sees pressure on both sides of the diaphragm.

ALL RUBBER
Our own high-quality interpretation of what is typically a commodity-grade diaphragm. A lower-cost solution for low-pressure applications.

DIAPHRAGM TYPES
ALL RUBBER



All rubber (homogeneous) diaphragms can be used in very low pressure applications. The same functionality of a fabric reinforced diaphragm applies to the all rubber diaphragms (just without the fabric).

METAL AND PLASTIC BONDING
Bonding occurs during the molding process for added strength and efficiency.during the molding process for added strength and efficiency.

DIAPHRAGM TYPES
METAL AND PLASTIC BONDING



Bellofram has the ability to bond metal or plastic inserts to the diaphragm. During the molding process, the insert becomes totally or partial encapsulated by the elastomer, creating a strong bond between the two. This bonding process eliminates costly assembly operations.

MOLDED DIE-CUT
Available in a variety of materials and trim patterns

DIAPHRAGM TYPES
MOLDED DIE-CUT



Any shape and any size, our flat/die-cut diaphragms can be all rubber, fabric reinforced, or double-coat. Various trim patterns are also optional.
